Hotel & Resort
Hotel & Resort are spots which provide those who take a break from the treadmill with a joy. Sound broadcasting system is needed in the interior spaces such as rooms, lobbies, restaurants and banquet halls as well as open spaces like the swimming pool, golf course, etc. Through BGM resonated serenely, it offers customers a luxurious and comfortable break, coveys necessary information to them via indoor/outdoor announcements.
Please create a hospitality brand image with the best service through Inter-M’s audio system to make people visit again.
System Block Diagram
Summary
Fill the building with 10W ceiling speakers and use the digital amplifier, DPA-300D to compose the sound solution.
Main controller 8 bus 6000 system, PX-6216 has audio matrix for multi bus broadcast and DSP functions. It also has DC power to be used when AC power is unavailable. BGM can be played using several source devices. Use the remote microphones to make announcements.
If scheduling function is needed, interlock the program timer, PW-6242A with multi voice file de-vice, PV-6232 to broadcast anytime when you want.
BOM (Bill of materials)
| Model name | Qty | Description | |
|---|---|---|---|
| Source | CD-6208 | 2 | Multi Source Player |
| NTU-100 | 1 | Network Tuner | |
| RM-02 | 1 | Gooseneck Dynamic Microphone | |
| PE-6103 | 1 | Chime & Siren | |
| ARM-911A | 1 | Automatic Remote Message | |
| PW-6242A | 1 | Program Timer | |
| PV-6232 | 1 | Multi Voice File | |
| RM-6024 | 2 | System Remote MIC Station | |
| Controller | EP-6216 | 1 | Emergency Panel |
| PX-6216 | 1 | Audio Matrix Controller | |
| ECS-6216MS | 1 | Emergency Combination System | |
| PD-6359 | 1 | Power Distributor | |
| PB-6207 | 1 | Battery Charger | |
| DIB-6000 | 1 | Direct Box | |
| Amplifier | PM-6228 | 1 | Monitor Panel |
| AFD-6218 | 1 | 9CH(Spare 1CH), Amp Fault Detector | |
| DPA-300D | 3 | 300W, 2CH, Digital Power Amplifier | |
| DPA-300S | 1 | 300W, 1CH, Digital Power Amplifier | |
| Speaker | CS-10F5 | 120 | 10W, Ceiling Speaker |
| SC-6224 | 1 | Speaker Line Checker |
