Performance Hall
_______
A theater is respire place between artist and audience. To have effective performance, we need to have system in accordance with size.
System is needed to deliver clear and find sound in middle-small performance, and powerful and vivid sound in big performance.
Inter-M has best sound equipment which is enough to digest any performance. Inter-M has installed which is fixed in the stage and touring system which is moveable. Please produce performance which is to give joy and emotively to audience with Inter-M Pro Audio system.
Small to Medium-sized Theater
Small to medium-sized theater is enable to have more appreciate with concentration due to close between stage and seats. Thus, It’s important to lead from spectators response and enhance performance concentration via delivering clear and vivid sound.
Inter-M Pro Audio system is enable to hear vivid sound from wherever. Please design with Inter-M sound system which is enable to have small and delicate sound up to strong sound.
System Block Diagram
Summary
It can be applied to small to medium-sized theater. Large-sized line array speakers are used for minimum sound pressure and even sound dispersion. Place the line array composed of 5 inch 160W 2 way line array speaker, CLA-5K and 15 inch 600W subwoofer, CLA-15SK on both sides to make the sound solution super powerful. Plus, it uses professional power amplifier, D Series as the main speaker system. 8 inch 150W point source speaker, SQ-8K and multi-channel amplifier, DSA-300E to compose the stage monitor environment.
High quality analog mixer, IMX Series and digital sound processor, CSP-4.8 provide easy-to-use operation and can be applied to various environments as it provides preset.
The dynamic microphone MH Series can be used to make stable but dynamic live concerts. Multi source player and recorder, CDR-01 can use various sound sources like CD, USB and SD card to play high quality sound and receive currently playing sound from the mixer to record and save in the SD card.
BOM (Bill of materials)
| Model name | Qty | Description | |
|---|---|---|---|
| Source | CDR-01 | 2 | SD Recorder/Multi Source Player |
| MH50 | 4 | Hyper Cardioid Dymamic Microphone | |
| Wireless Hand MIC | 2 | Wireless Hand Microphone | |
| Wireless Belt MIC | 1 | Wireless Belt Microphone | |
| Controller | KENSINGTON-416 | 1 | Audio Mixing Console (4Bus) |
| CSP-4.8 | 2 | Digital Signal Processor | |
| Wireless Receiver | 2 | Wireless Receiver | |
| SPAC-660 | 1 | Power Sequencer | |
| Amplifier | D-3000 | 2 | 600W, 2CH, Professional Network Amplifier with DANTE Network & DSP |
| D-6000 | 1 | a1200W, 2CH, Professional Network Amplifier with DANTE Network & DSP | |
| DSA-300E | 1 | 150W, 8CH, Digital SR Amplifier | |
| Speaker | CLA-5K | 8 | 5″, LF: 160W / HF: 30W, Compact Line Array Module/Passive Loudspeaker |
| CLA-15SK | 2 | 5″, 600W, Compact Flying-Sub Module/ Subwoofer | |
| SQ-8K | 8 | 8″, 150W, 2Way Passive Full Range Multi-Purpose Loudspeaker |
. [SMALL TO MEDIUM-SIZED THEATER] Small to Medium-sized Theater
Large-sized Theater
Large-sized theater overwhelms spectators with big space and magnificent.
Big sound system which is deliver even and vivid sound to long distance spectators is needful due to consideration of with composition seats. Inter-M provides dynamic and real sound with consideration of wide bandwidth and high sound pressure level and also it enables to increase site response with density sound via installing a verity of speakers. Please provides exciting time with dynamic performance with Inter-M sound system.
System Block Diagram
Summary
This system is for touring (rental type) purpose in large-sized theater. To minimize the SPL reduction by distance and to have stable SPL distribution, it uses large line-array speakers. It is designed to ease touring through symmetrical installation of 800W 12″ 2way Bi-amp line-array speaker TL22 and 2400W 18″ sub-woofer TS-28. In front stage area that has relatively insufficient SPL, 150W 8″ point speaker SQ-8K, professional power amplifier D series and 12″ 350W monitor speakers CMM-12K are installed.
Using dynamic microphone MH series for live vocal, the system can be used in stable mode.
Multi-source player/recorder CDR-01 is supporting various media player such as CD, USB, and SD card to play high quality music, and it can record/save to SD card the live music from the mixer.
BOM (Bill of materials)
| Model name | Qty | Description | |
|---|---|---|---|
| Source | CDR-01 | 2 | SD Recorder/Multi Source Player |
| MH50 | 4 | Hyper Cardioid Dymamic Microphone | |
| Wireless Hand MIC | 6 | Wireless Hand Microphone | |
| Wireless Belt MIC | 2 | Wireless Belt Microphone | |
| Controller | Digital Audio Mixer | 1 | Digital Audio Mixer(DANTE) |
| Wireless Receiver | 5 | Digital Signal Processor | |
| Switching Hub | 1 | Wireless Receiver | |
| SPAC-660N | 1 | Power Sequencer | |
| Amplifier | DANTE, DSP Power Amp | 6 | 300W, DANTE, DSP Power Amplifier |
| D-3000 | 6 | 600W, 2CH, Professional Network Amplifier with DANTE Network & DSP | |
| D-6000 | 2 | 600W, 2CH, Professional Network Amplifier with DANTE Network & DSP | |
| Speaker | TL22 | 16 | 12″, LF:800W/HF:200W ,Dual 2Way Bi-amp Line Array |
| TS28 | 4 | 18″, 3400W, Dual Line Array SubWoofer for Touring | |
| CMM-12K | 12 | 12″, 350W, Coaxial Multi-purpose Monitor System | |
| CSQ-10K | 4 | 10″, 280W, 2Way Passive High Power Loudspeaker |
